The Wuzhi-10 is a professional armed helicopter equipped by the People's Liberation Army, the first professional armed helicopter of the People's Liberation Army, and also a self-developed professional armed helicopter from various Asian countries. Ending the long history of the People's Liberation Army Army Aviation Corps relying on French Dolphin helicopters for modification and use as armed helicopters, greatly improving the aviation assault and anti armor capabilities of the People's Liberation Army Aviation Corps.

武直-10采用串列雙座設計，在設計上符合西方武裝直升機的主要特征。機體采用傳統布局，4片槳葉的尾槳位于尾梁左側，采用涵道式尾槳設計，水平安定面位于尾梁頂部。武直-10機身呈半硬式機體結構，采用多種復合材料，使用有源矩陣液晶顯示器（TFT）和玻璃座艙構型。

The Wuzhi-10 adopts a tandem double seater design, which conforms to the main characteristics of Western professional armed helicopters in design. The body adopts a traditional layout, with a four blade tail rotor located on the left side of the tail beam and a culvert tail rotor design. The horizontal stabilizer is located at the top of the tail beam. The Wuzhi-10 body is a semi rigid body structure, made of various composite materials, using an active matrix liquid crystal display (TFT) and a glass cockpit configuration.

武直-10機身兩側裝有一對短翼，每片短翼下有兩個掛載點，可搭載不同種類的。武直-10短翼前后緣都裝有一對紅外線導彈發射架，可搭載空對空導彈或空對地導彈。后部外掛架還可以搭載多聯裝火箭彈發射巢。機身左側的機艙門上設有向后延伸的登機梯，可讓艙內的駕駛員和副駕駛員和兩名外載操縱人員一同從機身上部登機。武直-10機身前上方裝有一座20毫米口徑的旋轉機炮塔，兩側各有一組短翼，每組短翼下有兩個掛載點，可搭載不同種類的。

The Wuzhi-10 is equipped with a pair of short wings on both sides of the fuselage, with two mounting points under each short wing, which can carry different types of weapons. The front and rear edges of the Wuzhi-10 short wing are equipped with a pair of infrared missile launchers, which can carry air to air missiles or air to ground missiles. The rear external hanger can also carry multiple rocket launcher nests. The cabin door on the left side of the fuselage is equipped with a backward extending boarding ladder, which allows the pilot, co pilot, and two external weapon operators inside the cabin to board the aircraft from the upper part of the fuselage. There is a 20mm caliber rotating turret located above the front of the Wuzhi-10 fuselage, with a set of short wings on each side. There are two mounting points below each set of short wings, which can carry different types of weapons.

總的來說，武直-10是人民解放軍裝備的一種武裝直升機，在設計上符合西方武裝直升機的主要特征。

Overall, the Wuzhi-10 is a professional armed helicopter equipped by the People's Liberation Army, and its design conforms to the main characteristics of Western professional armed helicopters.
